189020.15AK  Fuse-Link

GZAK-Fuse-Link | 6,3x32 | F | 15A |
AC 500V, DC 125V | axial leaded

Icon CE
189020.15AK

Download PDF Contact us

General product data

Item number 189020.15AK
Type Fuse-Link
Product group Miniature Fuse-Link
Product subgroup Cylindrical with Push on Caps
Rated current 15A
Rated voltage AC 500 V / DC 125 V
Rated breaking capacity 1500A AC 500V/DC 125V
Characteristic F
Dimensions 6.3x32
Indicator / Striker Pin
Contact Push on caps
Approvals Icon CE

Downloads

3D file 3D file
Web PDF Web PDF

Request documents

Applications

Battery energy storage systems (BESS)

Fuse-link solutions for a reliable energy transition

Battery energy storage systems (BESS)

Fitting Accessories

204101

204101  Push-on caps

GZAK-Push-on caps | 20A

Product details Download

Product family

189020

189020  Fuse-Link

Size Dimensions Rated current Rated voltage Characteristic Rated breaking capacity PDF
6.3x320.16A - 25AAC 440 VF1500A AC 440V

61 Article(s)

Item number Size Dimensions Rated current Rated voltage Characteristic Rated breaking capacity
189020.36.3x323AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.4AK6.3x324AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.4AK-GT6.3x324AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.4IP6.3x324AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.56.3x325AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.76.3x327AAC 500 VF1500A AC 500V Details
189020.7IP6.3x327AAC 500 VF1500A AC 500V Details
189020.86.3x328AAC 500 VF1500A AC 500V Details
189020.8IP6.3x328AAC 500 VF1500A AC 500V Details
189020.16.3x321AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.1,256.3x321,25AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.1,66.3x321,6AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.1,6IP6.3x321,6AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.12,5AK6.3x3212,5AAC 500 V / DC 125 VF1500A AC 440V Details
189020.12,5IP6.3x3212,5AAC 500 V / DC 125 VF1500A AC 500V Details
189020.156.3x3215AAC 500 V / DC 125 VF1500A AC 500V Details
189020.15AK6.3x3215AAC 500 V / DC 125 VF1500A AC 500V/DC 125V Details
189020.166.3x3216AAC 500 V / DC 125 VF1500A AC 500V Details
189020.16IP6.3x3216AAC 500 V / DC 125 VF1500A AC 500V Details
189020.1AK6.3x321AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.206.3x3220AAC 440 VF1500A AC 440V Details
189020.20AK6.3x3220AAC 440 VF1500A AC 440V Details
189020.20IP6.3x3220AAC 440 VF1500A AC 440V Details
189020.256.3x3225AAC 440 VF1500A AC 440V Details
189020.3,156.3x323,15AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.3,15IP6.3x323,15AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.3IP6.3x323AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.46.3x324AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.5AK6.3x325AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.5IP6.3x325AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.5SMD6.3x325AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.6,36.3x326,3AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.6,3AK6.3x326,3AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.6,3IP6.3x326,3AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.6,3THT6.3x326,3AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.0,166.3x32160mAAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.0,26.3x32200mAAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.0,256.3x32250mAAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.0,25IP6.3x32250mAAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.0,3156.3x32315mAAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.0,315IP6.3x32315mAAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.0,46.3x32400mAAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.0,56.3x32500mAAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.0,5AK6.3x32500mAAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.0,5AK-GT6.3x32500mAAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.0,5IP6.3x32500mAAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.0,636.3x32630mAAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.0,63AK6.3x32630mAAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.0,63AK-GT6.3x32630mAAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.0,63IP6.3x32630mAAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.0,86.3x32800mAAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.106.3x3210AAC 500 V / DC 125 VF1500A AC 500V Details
189020.10IP6.3x3210AAC 500 V / DC 125 VF1500A AC 500V Details
189020.12,56.3x3212,5AAC 500 V / DC 125 VF1500A AC 500V Details
189020.1IP6.3x321AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.1SMD6.3x321AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.26.3x322AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.2,56.3x322,5AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.25IP6.3x3225AAC 440 VF1500A AC 440V Details
189020.2AK6.3x322AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
189020.2IP6.3x322AAC 500 V / DC 450 VF50kA AC 500V/1.5kA DC 450V Details
