161000.4 Fuse-Link

GSMB-Fuse-Link | 4,5x8 | F | 4A |
AC 250V, DC 125V

IEC 60127-4/2

General product data

Item number	161000.4
Type	Fuse-Link
Product group	Miniature Fuse-Link
Product subgroup	SMD Block-Type
Rated current	4A
Rated voltage	250 V
Rated breaking capacity	100A AC 250V DC 125V
Characteristic	F
Dimensions	4.5x8
Indicator / Striker Pin
Contact
Standard IEC	IEC 60127-4/2
Approvals

Downloads

3D file	3D file
Web PDF	Web PDF

Request documents

Applications

Fuse-link solutions for a reliable energy transition

Battery energy storage systems (BESS)

Product family

161000 Fuse-Link

Size	Dimensions	Rated current	Rated voltage	Characteristic	Rated breaking capacity	PDF
	4.5x8	0.5A - 6.3A	250 V	F	100A AC 250V DC 125V	Download PDF

19 Article(s)

Item number	Dimensions	Rated current	Rated voltage	Characteristic	Rated breaking capacity
161000.0,5GT	4.5x8	500mA	250 V	F	100A AC 250V DC 125V	Details to product 161000.0,5GT
161000.0,63	4.5x8	630mA	250 V	F	100A AC 250V DC 125V	Details to product 161000.0,63
161000.0,63GT	4.5x8	630mA	250 V	F	100A AC 250V DC 125V	Details to product 161000.0,63GT
161000.0,8GT	4.5x8	800mA	250 V	F	100A AC 250V DC 125V	Details to product 161000.0,8GT
161000.1	4.5x8	1A	250 V	F	100A AC 250V DC 125V	Details to product 161000.1
161000.1,25GT	4.5x8	1,25A	250 V	F	100A AC 250V DC 125V	Details to product 161000.1,25GT
161000.1,6GT	4.5x8	1,6A	250 V	F	100A AC 250V DC 125V	Details to product 161000.1,6GT
161000.2,5GT	4.5x8	2,5A	250 V	F	100A AC 250V DC 125V	Details to product 161000.2,5GT
161000.2	4.5x8	2A	250 V	F	100A AC 250V DC 125V	Details to product 161000.2
161000.2,5	4.5x8	2,5A	250 V	F	100A AC 250V DC 125V	Details to product 161000.2,5
161000.2GT	4.5x8	2A	250 V	F	100A AC 250V DC 125V	Details to product 161000.2GT
161000.3,15	4.5x8	3,15A	250 V	F	100A AC 250V DC 125V	Details to product 161000.3,15
161000.3,15GT	4.5x8	3,15A	250 V	F	100A AC 250V DC 125V	Details to product 161000.3,15GT
161000.4	4.5x8	4A	250 V	F	100A AC 250V DC 125V	Details to product 161000.4
161000.4GT	4.5x8	4A	250 V	F	100A AC 250V DC 125V	Details to product 161000.4GT
161000.5	4.5x8	5A	250 V	F	100A AC 250V DC 125V	Details to product 161000.5
161000.5GT	4.5x8	5A	250 V	F	100A AC 250V DC 125V	Details to product 161000.5GT
161000.6,3	4.5x8	6,3A	250 V	F	100A AC 250V DC 125V	Details to product 161000.6,3
161000.6,3GT	4.5x8	6,3A	250 V	F	100A AC 250V DC 125V	Details to product 161000.6,3GT
